2D: Cascade Elevator

Drive System

Elevators need motors to power them. Once you have the rigging planned out you can figure out where you can fit the motors to drive the base elevator stage.

Elevator drive system close up

Reference Design

The reference design utilizes a vertical chain with the TTB chain comb and NEO motors with MAX planetary gearboxes.
